DJ-V27T
T: TX222 - 224.995MHz RX216 - 249.995MHz
DJ-V47 / S47
T: TX430 - 449.995MHz RX410 - 470MHz approx.
E: TX/RX 430 - 439.995MHz
Modulation: F3E (FM)
Frequency step: 5,10, 12.5, 15, 20, 25, 30kHz step
Memory channel: 200 channels + 1 call channel + 1 Repeater-Access parameter memory
Antenna impedance: 50ohm unbalanced
Frequency stability: DJ-V17 / S17: +/- 5ppm
DJ-V27/V47 / S47: +/- 2.5ppm
Supply voltage: DC 7.0 - 16.0V (EXT DC-IN)
Current consumption:
(Typical value) TX at High power V/S17 1.4A, V27T 1.6A, V/S47 1.7A
RX at 500mW AF out: 250mA
Stand-by: V/S17 70mA, V27T 80mA, V/S47 80mA
Battery-save ON: average 26mA
Temperature range: Unit -10digC to 60digC (+14digF to +140digF) Battery packs: -10digC to +45digC (+14digF to +113digF)
Ground: Negative
Dimensions: 58(W)x110(H)x36.4(D)mm (2.28"(W)x4.33"(H)x1.43"(D)) with EBP-65N w/o projection
Weight: Approx.280g (9.9oz) with EBP-65N & antenna
Transmitter
Power output:
(Approx.value) V/S17: 5W (with EBP-65N) 5W (with DC 13.8V) 0.8W (LOW output)
V27T: 5W (with EBP-65N) 5W (with DC 13.8V) 0.8W (LOW output)
V/S47: 4.5W (with EBP-65N) 5W (with DC 13.8V) 0.8W (LOW output)
Modulation: Variable reactance
Spurious emission: -60dB or less
Max. deviation: +/- 5KHz
Mic. impedance: 2Kohm
Receiver
System: Double-conversion super heterodyne
Sensitivity: -14.0dBu (0.2uV) or less
Intermediate frequency: DJ-V/S17: 1st IF 21.7MHz 2nd IF 450kHz
DJ-V/S47 & V27T: 1st IF 38.85MHz 2nd IF 450kHz
Selectivity: -6dB: 12kHz or more -60dB: 26kHz or less
AF output: 500mW (MAX) / 400mW (8ohm, 10% distortion)
